SUN-15/17K-G03

The Deye SUN-15/17K-G03 is a three-phase string inverter for residential and commercial solar PV systems. With 2 MPP trackers and up to 98.5% efficiency, it supports zero export and VSG applications, and offers optional Anti-PID and string intelligent monitoring.

SUN-15/17K-G03

Key Features

  • High Efficiency: Achieves a maximum efficiency of up to 98.5% with 2 MPP trackers.
  • Low Start-up Voltage: Starts up at 250V, ensuring stable operation once sufficient DC input is available.
  • Zero Export Application: Supports zero export functionality, allowing you to manage your energy consumption and maximize self-consumption.
  • VSG Application: Enables voltage support capabilities, contributing to grid stability.
  • String Intelligent Monitoring: Offers optional string intelligent monitoring for enhanced system diagnostics.
  • Wide Output Voltage Range: Supports an AC grid voltage range of 277-460 Vac, providing flexible compatibility with various grid configurations.
  • Anti-PID Function: Optional anti-PID function helps prevent power degradation caused by the PID phenomenon in PV modules.
  • Comprehensive Protection: Includes DC reverse-polarity protection, AC short circuit protection, AC output overcurrent/overvoltage protection, insulation resistance protection, ground fault monitoring, anti-islanding protection, temperature protection, and DC Type II / AC Type II surge protection.
  • Monitoring & Communication: Supports RS485/RS232/WiFi/LAN interfaces for remote monitoring and communication.
  •

General Data

  • Inverter Topology: Transformerless
  • Cabinet Size: 330 × 472 × 202 mm (W × H × D)
  • Weight: 15 kg
  • Cooling Type: Smart Cooling
  • Warranty: 5 Years

Standards & Certifications

  • Grid Regulation: EN50549-1, IEC61727, IEC62116, IEC60068, IEC61683, VDE 0126-1-1, RD1699, UNE 206006 IN, UNE 206007-1 IN, UNE 217001 IN
  • EMC/Safety: IEC 62109-1/-2, IEC 61000-6-1, IEC 61000-6-3, IEC 61000-3-11, IEC 61000-3-12
  • Ingress Protection Rating: IP 65

Technical Specifications

Model SUN-15K-G03 SUN-17K-G03
PV String Input Data
Max. DC Input Power (kW) 19.5 22.1
Max. DC Input Voltage (V) 1000
Start-up DC Input Voltage (V) 250
MPPT Operating Range (V) 200~850
Max. DC Input Current (A) 13+26
Max. Short Circuit Current (A) 19.5+39
No. of MPPT Trackers / No. of Strings per MPPT Tracker 2 / 1+2
AC Output Side
Rated Output Power (kW) 15 17
Max. Active Power (kW) 16.5 18.7
Rated AC Grid Output Current (A) 21.8 24.6
Max. AC Output Current (A) 23.9 27.1
Rated AC Grid Voltage (V) 220 / 380, 230 / 400
AC Grid Voltage Range (V) 277Vac~460Vac (This may vary with grid standards)
Operating Phase Three phase
Rated Grid Frequency (Hz) 50 / 60 (Optional)
Grid Frequency Range (Hz) 47~52 or 57~62 (Optional)
Output Power Factor 0.8 leading to 0.8 lagging
Grid Current THD <3%
DC Injection Current (mA) <0.5%
Efficiency
Max. Efficiency 98.5%
Euro Efficiency 97.5%
MPPT Efficiency >99%
Equipment Protection
DC Reverse-Polarity Protection Yes
AC Short Circuit Protection Yes
AC Output Overcurrent Protection Yes
Output Overvoltage Protection Yes
Insulation Resistance Protection Yes
Ground Fault Monitoring Yes
Anti-islanding Protection Yes
Temperature Protection Yes
Integrated DC Switch Yes
Remote Software Upload Yes
Remote Change of Operating Parameters Yes
Surge Protection DC Type II / AC Type II
Interface
Communication Interface RS485/RS232
Monitor Mode WiFi/LAN
Display LCD1602
DC Connection MC-4 mateable
AC Connection IP65 rated plug
General Data
Operating Temperature Range (°C) -25 to +65°C
Permissible Ambient Humidity 0–100%
Max. Operating Altitude Without Derating (m) 2000m
Noise (dB) <40 dB
Internal Consumption <1W (Night)
Ingress Protection (IP Rating) IP65
Inverter Topology Transformerless
Cabinet Size (WxHxD mm) 330×472×202
Weight (kg) 15
Designed Lifetime >20 years
Warranty 5 Years
Type of Cooling Smart Cooling
Grid Regulation EN50549-1, IEC61727, IEC62116, IEC60068, IEC61683, VDE 0126-1-1, RD1699, UNE 206006 IN, UNE 206007-1 IN, UNE 217001 IN
Safety EMC/Standard IEC 62109-1/-2, IEC 61000-6-1, IEC 61000-6-3, IEC 61000-3-11, IEC 61000-3-12
