Deye Battery BOS-A PACK 7.68

7.68 kWh

Features

Integrated PACK 7.68 kWh (38.4V / 200Ah): reduced line loss, enhanced energy density
Support 160A max charge & 160A max discharge
Flexible Expansion: 7-21 packs in series, max. 16 clusters in parallel

Advanced BMS

Intelligent BMS with auto charge/discharge and cell voltage balancing
Comprehensive protection: over-discharge, over-charge, over-current, and temperature protection
Communication via CAN2.0, plus Bluetooth App and USB for BMS upgrade

SMART CONTROL AT YOUR FINGERTIPS

Auto Charge/Discharge: automatic charge/discharge management with cell voltage balancing
Remote Monitoring: communication via CAN2.0, plus Bluetooth App and USB for BMS upgrade
Automatic Warning: LED indicator (Yellow: battery high voltage power on, Red: battery system alarm) and SOC / fault code display

Technical Data Specification

Model	BOS-A-Pack7.68
Battery Chemistry	LiFePO₄
Nominal Voltage	38.4 V
Capacity	200 Ah
Nominal Energy	7.68 kWh
Max Charge/Discharge Current	160 A
Charge Temperature	0 ~ 55 °C
Discharge Temperature	-20 ~ 55 °C
Storage Temperature	0 ~ 35 °C
Recommended Depth of Discharge (DoD)	90%
Dimensions (W×D×H)	576 × 632 × 135.2 mm
Weight	66 kg
IP Rating	IP20
Communication	CAN2.0
